VG1047010050 曲轴后油封总成

济南向前汽车配件有限公司供应VG1047010050 曲轴后油封总成【VG1047010050】，价格18.00元/件,下面是详细参数及照片。

产品：	Crankshaft rear oil seal
图号：	VG1047010050
车型：	HOWO
品牌：	Forward
Weight：	0.2Kg
单价：	18.00元/件
所在地：	山东-济南市-山东济南泉利重配城
有效期至：	长期有效
最后更新：	2025-04-23 16:01
浏览次数：	364

公司基本资料信息

济南向前汽车配件有限公司
[VIP第1年] 指数:7
通过认证 [诚信档案]
已缴纳 0.00 元保证金
联系人张兵(先生)
电话0531-68827106
手机18705311600
地区山东-济南市-山东济南泉利重配城
地址山东省济南市天桥区蓝翔路57号泉利汽配城17-115号

详细说明

The assembly assembly of engine crankshaft rear oil seal comprises a positioning connection and mutual adaptation base and rear oil seal seat, and also includes a guide sleeve and a pressure sleeve. The crankshaft rear oil seal is mounted on the inside of the rear oil seal seat through the guidance positioning of the guide sleeve and the pressure action of the pressure sleeve. The rear oil seal seat is in the shape of a step, and the base is provided with a groove. The size of the bottom of the lower step of the rear oil seal seat is matched with the groove. A circular hole is arranged in the middle of the base, and the guide sleeve is installed and positioned in the circular hole; The pressure sleeve is fitted on the outside of the guide sleeve and matched with the clearance. The pressure sleeve presses the crankshaft rear oil seal on the lower step inside the rear oil seal seat through the guidance positioning of the guide sleeve. The base and the rear oil seal seat are fixed by the positioning pin. The locating pin is a locating round pin or locating rhomboid pin. The assembly component of the utility model solves the problem of difficult pressing when the oil seal is pressed into the inner side of the step shaped rear oil seal seat. And to ensure the assembly of oil seal flatness, pressure depth and other assembly requirements. The assembly efficiency of the rear oil seal is improved, and the precision and quality stability of the product are improved.
