DZ9114420671锥齿轮副 i=5.73 i=6.72

济南向前汽车配件有限公司供应DZ9114420671锥齿轮副 i=5.73 i=6.72【DZ9114420671】,价格0.00元/Pcs/Set,下面是详细参数及照片。

产品: Bevel gear pair
图号:

DZ9114420671

车型: SHACMAN 6*6 8*8
品牌: Forwar
Size:mm: 300*310*250
Weight:kg: 21.5
单价: 面议
所在地: 山东-济南市-山东济南泉利重配城
有效期至: 长期有效
最后更新: 2025-04-23 16:10
浏览次数: 395

公司基本资料信息
  • 济南向前汽车配件有限公司
  • VIP [VIP第1年] 指数:7
  •       通过认证 [诚信档案]
  • 已缴纳 0.00 元保证金
  • 联系人张兵(先生)
  • 电话0531-68827106
  • 手机18705311600
  • 地区山东-济南市-山东济南泉利重配城
  • 地址山东省济南市天桥区蓝翔路57号泉利汽配城17-115号
详细说明
DZ9114420671Forwar
 Bevel gear action:

     Bevel gears are used to transfer motion and power between two intersecting axes. In general machinery, the Angle of intersection between two shafts of bevel gears is equal to 90° (but may not be equal to 90°). Similar to cylindrical gears, bevel gears have indexing cones, tip cones, root cones and base cones. The cone has a big end and a small end, and the corresponding circle of the big end is called the dividing circle (its radius is R), the addendum circle, the root circle and the base circle respectively. The motion of a pair of bevel gears is equivalent to that of a pair of nodal cones for pure rolling

前转向驱动桥主减速器

DZ91189400004Steering drive axle

SZ940000017

SZ940000505

SZ940000508

SZ940000510

6*6     8*4      8*8



9 DZ91149320000 Rear axle main reducer housing assembly
10 DZ9114420671  Bevel gear pair i=5.73
  199000420034 Bevel gear pair i=6.72
11 32315 Tapered roller bearing
12 199012320133 Sealing ring
13 199012320173 Adjusting gasket (on demand)
15 199012320103 bearing
16 188000320002 Adjusting gasket (on demand)
17 30312 Tapered roller bearing
18 DZ9114320902 Oil seal
20 DZ9112320627 Flange assembly
